    Non Toxic Fiber Laser Marking Machine , Handheld Laser Marking Machine 1060nm

    Ask Lasest Price
    Brand Name : Riselaser
    Model Number : RL-20P
    Certification : ISO9001:2008
    Price : negotiation
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 2000 units/ month
    Delivery Time : 5-9 working days
    • Product Details
    • Company Profile

    Non Toxic Fiber Laser Marking Machine , Handheld Laser Marking Machine 1060nm

    Deep Engraving Fiber Laser Marking Machine


    Product Introduction

    Laser marking machines use laser beams to mark various surfaces permanently. Marking effect is to reveal the deep substance through the evaporation of surface substance, or to “carve” the trace through the chemical and physical changes of surface substance caused by light energy, or to burn part of the substance through light energy, showing the required pattern, text and other information.


    Advantages

    • No consumable materials, non-toxic, no environmental pollution, high environmental protection
    • The marking graphics can be designed conveniently in the computer, and can be marked arbitrarily
    • Laser marking has good abrasion resistance, is not easy to erase, and has strong anti-counterfeiting function
    • Non-contact processing, high efficiency, no mechanical stress on the material, no damage to the processed object, accurate, elegant
    • Red light preview: the printed content can be displayed on the workpiece in advance through the red light preview function. What you see is what you get
    • Special marking software, can text, graphics, date, time, serial number, bar code, automatic jump number and other information
    • Laser core life of more than 100,000 hours, long service life

    Parameters

    Laser Power20w
    Laser Wavelength1060nm
    Beam Quality<2(M2)
    Laser TypePulse or continuity
    Cooling SystemBuilt-in air cooling
    Marking Line Speed7000 mm/s or less
    Marking RangeStandard plane 125mm*125mm can be customized 160mm*160mm, 300mm*300mm
    Minimum CharactersThe 0.15mm
    Minimum Line WidthThe 0.012mm

    Details

    Laser Source

    Shenzhen MAX overall manufacturing, leading domestic laser manufacturers. Standard IPG transmission fiber. The laser has the advantages of good beam quality, high electro-optical conversion efficiency, low power consumption and no maintenance, and its service life is over 100,000 hours.

    High Speed Scanning Galvanometer

    SCANLAD scanning galvanometer, full digital signal, super anti-interference ability. High precision, short delay, fast speed, small temperature drift, especially suitable for all kinds of high precision, high speed marking requirements.


    The control software

    ECARD control software, beautiful interface, powerful function, detailed parameters, simple operation, can describe any pattern, text, bar code, two dimensional code processing.

    Precision Z-axis Lifting Platform

    One-dimensional linear module, manual control, positioning accuracy of 0.01mm.


    Application

    Can be a variety of metal, non-metallic materials for processing. Especially for high hardness, high melting point, brittle material marking more obvious advantages.

    Belongs to the non-contact processing, does not damage the product, no tool wear, marking good quality.

    The laser beam is fine, the processing material consumption is small, and the processing heat influence area is small.

    High processing efficiency, the use of computer control, easy to achieve automation.


    Certificate



    Shipping


    Our Factory

    FAQ
    Q: Can I get some discount if I order more?
    A: Yes,The more you order,the more you save.
    Q:How to choose suitable model?
    A:Please provide a photo of the product you used before or advise us your needs, we will give suggestion .
    Q:Why choose your company?
    A:We are a professional Industrial Solutions company in China. We’re more familiar with customer’s marking or engraving applications. So we’re in a position to recommend a more suitable model and provide free professional technology.
    Q: Do you have the manual of machine?
    A: Yes,we can provide manual,CD software and video to help you operate the machine expertly.
